Product Features:
● High current and voltage carrying capacity.
● Simple, quick and safe effective field assembly.
● It can be used in the outdoor iron environment.
Structure:
| Insulation | PPO |
| Contact material | Copper, Thorium silver |
| Cable Spec | 2.5 mm簡, 4mm簡, 6mm簡 |
| Connection method | Bayonet Mount adapter |
Specifications:
| Rated current | 30A |
| Rated Voltage | DC 1000V |
| Contact Resistance | 0.5m惟 |
| Operating Temperature | -40擄C to 85擄C |
| Protection Degree | IP67 |
